Construction Cables
Created with Pixso. 500V 750V PVC Sheathed Flexible Mineral Insulated Copper Cable RVVP KVVP2

500V 750V PVC Sheathed Flexible Mineral Insulated Copper Cable RVVP KVVP2

Brand Name: CR
Model Number: KVV22
MOQ: Any Trail Order ls Welcomed
Price: $0.76-2.45
Delivery Time: 3-7 Working Days
Payment Terms: L/C,T/T,D/A,D/P, Western Union,MoneyGarm,E-Checking etc.
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE CCC ISO RHOS
Insulation Material:
Polyvinyl Chloride (PVC)
Jacket Color:
Black, Optional
Conductor Type:
Stranded
Conductor Material:
Copper
Standards And Certifications:
UL Listed, RoHS Compliant
Working Temperature:
90°C
Application:
Indoors Job, In Trenches, In Ducts And In Ground, Etc.
Jacket:
PVC
Product Name:
Control Cable With Steel Tape Armor
Insulation:
PVC
Conductor:
Copper
Voltage:
450/750V, 300/50V, 300/500V,
Packaging Details:
Standard Export Strong Packing
Supply Ability:
Order, In Stock
Highlight:

500V mineral insulated copper cable

,

750V mineral insulated copper cable

,

KVVP2 sheathed flexible cable

Product Description

Control & Sinal Series Cables300/500V 300/50V 450/750V Copper Polyvinyl Chloride Insulated and Polyvinyl Chloride Sheathed Flexible Cable (RVV/RVVP/KVV/KVV22/KVVP2/KVVP2-22)



Application
Wiring environment apply to indoors job, in trenches, in ducts and in ground, etc. able to withstand mechanical force on heavy level.


Standard
China: GB/T 9330-2020
Other standards such as IEC, BS, DIN and ICEA upon request.


Brief construction

1) Conductor: Copper
2) Insulation: PVC
3) Armour: Steel Tape
4) Sheath: PVC
5)Other special characteristics: Design and manufacture according to the requirements of customers.

Service performance
1) Rated voltage: 450/750V
2) Long-term working temperature: not be higher than 70°C
3) When laying the cable, the ambient temperature should not lower than 0°C
4) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm;
Bending radius≥6D as cable overall diameter>25mm.

500V 750V PVC Sheathed Flexible Mineral Insulated Copper Cable  RVVP KVVP2 0


Customization options

Customized logo (Min. order: 1,000 meters)
Customized packaging (Min. order: 1,000 meters)
